Moreover, an optional 3D Software Extension is available, which enhances the reproduction of intricate designs and engravings with precise detail. This extension is designed to manage STL files and enables the faithful 3D reproduction of solids, maintaining their true proportions. The supported file types for the 3D Laser Marking Machine include STL and 3D files.
Get a QuoteTo facilitate efficient marking, the machine incorporates 3 Axis Auto-Movement
functionality. This feature enables the management of axis positions through software, allowing for the
sequential marking of multiple objects on the same tray, regardless of their varying shapes and sizes. By
utilizing Cartesian coordinates, this module enables the programming of axis movements based on the objects’
positions, thereby increasing productivity through simultaneous marking.
The 3D laser marking machine
excels in its ability to dynamically focus across three axes, with a range of 25-30 mm. This capability
enables the real-time tracking of deep curves and is supported by an advanced 3D scanning galvanometer head
and control system. Whether for large-format marking, deep engraving, or curved surface marking, this
machine can cater to a diverse range of processing needs.
Furthermore, the focal length position of
the laser marking machine can be precisely controlled, allowing for automatic adjustments along the Z-axis
during the 3D deep marking process. This ensures minimal spot size and guarantees a uniform graphic effect
after marking on the object.
| Laser Type | Fiber Laser |
|---|---|
| Laser Power | 50W, 60W, 100W |
| Laser Wave Length | 1064 nm |
| Marking Area | 300mm*300mm |
| Lifting Range | 250mm |
| Working Type | 3D Curve Engraving |
| Focus Adjust | 40MM |
| Laser Source Brand | MRLT OEM, Max, Raycus, JPT, IPG (Germany) |
| Laser Source Lifetime | >1,00,000 Hours |
| Marking Line Width | 0.01-0.1 mm |
| Marking Depth | depends on material and Design up to 2-4 mm |
| Max. Marking Speed | 8000 mm/sec – 12000 mm/sec |
| Power Adjustment | 0 to 100% |
| Repeatable Accuracy | 0.001 mm |
| Min. Letter | 0.15 mm |
| Cooling System | Panel AC |
| Modulation Frequency | 20kHz~200kHz |
| Working Voltage | AC220V/110V |
| Unit Power | < 1KW |
| Max Power consumption | 1000W watts |
| Software | EZCAD software Upgraded Version |
| Packing Size (L*W*H) | 28 inches * 28 inches * 38 inches |
| Gross Weight | 120/150 kg (Approx.) |
| Colour | Standard Blue and White / Grey and White |
| Laser Warranty | 2 Years Warranty |
| Machine Warranty | 1 Year Warranty |
Looking for reliable laser cutting, marking, or welding solutions? Share your requirements with MR Laser Machine, and our expert team will assist you with the right machine and technical guidance.
Advanced 3D scanning galvanometer head and control system.
Delivers permanent and exceptional high-quality marks on various materials.
Ensures high efficiency and very low operation cost for industrial marking.
Easily accessible and capable of marking even on irregular and curved surfaces.
Non-contact process requires no special working environmental setup.
Guarantees the minimized metallurgical and mechanical damage to the workpiece.
Direct writing of patterns can be easily established with full automation support.
Using computer-controlled movement of the beam or sample for precise pattern writing.
Provides precise beam positioning and highly localized energy transfer to the workpiece.
Highly localized energy transfer to the work piece ensures accurate and clean marking results.
Highly reproducible working process that is extremely high speed and effective.
Keeps the heat load to an absolute minimum during deep marking process.
Safe and completely contamination-free industrial marking operation.
